2 SECTION ALUMINUM TELESCOPIC SCAFFOLDING WITH ROPE SYSTEM

Mobile and practical use. It has wide areas of use. Special joint and rope system allow to adjust the working height easly and create a safe working environment. Lockable wheels and steel balance legs minimize swaying. Carrying capacity is 2 kN/m2.

Go Product

Technical Table Product Features

Technical Specifications

The core dimensions and usage details of this product are presented in the table below.

Model No	Height	Profile size	Number of steps	Platform Size	Working Height	Weight
CL 2422-S	2 x 2 mt	90x25mm	4 x 6	170x60 cm	375 cm	67 Kg
CL 2423-S	2 x 2.5 mt	90x25mm	4 x 8	170x60 cm	485 cm	73 Kg
CL 2424-S	2 x 3 mt	90x25mm	4 x 10	170x60 cm	597 cm	80 Kg
CL 2425-S	2 x 3.5 mt	90x25mm	4 x 12	170x60 cm	706 cm	85 Kg
CL 2426-S	2 x 4 mt	90x25mm	4 x 14	170x60 cm	822 cm	92,5 Kg
CL 2427-S	2 x 5 mt	90x25mm	4 x 17	170x60 cm	990 cm	101 Kg

Product Features

✓Easy move and fix by the help of wheels and fixing rods.

✓Adjustable leg system.

✓Easy to lift up and down by the rope system.

✓Adjustable in the level wanted by the special aluminum lock.

✓Easy climb up by the cover.

✓Easy balance by the help of fixing telescopic profile.

✓Easy assemble by the demountable parts.

✓Industrial use.

✓Very light weight and high resistance to load.

✓Long life stainless.

✓Maximum endurance.
